Solar Inverter
Product Description
Our solar inverters meet international certifications and standards and safety regulations under IEC62109-1, IEC62109-2, grid regulations under VDE-ARN4105, VDE0126, AS4777, NRS2017, G98, G99, EN50438. EMC under EN61000-6-1, EN61000-6-3.
Solar inverters are an integral part of the solar system. All the components of the solar system are to be well studied and balanced, set together in a harmonious method to provide maximum efficiency. They are sold together as a complete solar energy solution.
SOLAR INVERTER SPECIFICATIONS
| Battery Type: | Lead-acid or Li-ION |
| Battery Voltage Range (V) | 40~60V |
| Peak Power | 2 times of rated power, 10S |
| Operating Temperature Range (C) | -25~60C > 45C Derating |
| Cooling | Fan |
| Noise | <30 |
| Communication with BMS | RS485; CAN |
| Protection Degree | IP65 |
| Installation Style | Wall-mounted |
SOLAR INVERTER FEATURES
- PV Arc Fault Detection
- PV Input Lighting Protection
- Anti- islanding Protection
- PV String Input Reverse Polarity Protection
- Insulation Resistor Detection
- Residual Current Monitoring Unit
- Output Over Current Protection
- Output Shorted Protection
- Output Over Voltage Protection
Solar Inverter Models HB-H-3.6 K-EU & HB-H-5K-EU
The following solar inverters are mainly used for households, residential or light commercial use. The following are the specifications for the inverter models HB-H-3.6 K-EU and HB-H-5K-EU
| HB-H-3.6 K-EU | HB-H-5K-EU | |
| Battery Input Data | ||
| Max. Charging Current (A) | 90A | 125A |
| Max. Discharging Current(A) | 90A | 125A |
| Charging Curve | 3 Stages/ Equalization | 3 Stages/ Equalization |
| External temperature sensor | Optional | Optional |
| Charging strategy for Li-Ion Battery | Self-adaptation to BMS | Self-adaptation to BMS |
| AC Output Data | ||
| Rated AC Output and UPS Power (W) | 3600W | 5000W |
| Peak Power (off-grid) | 2 times of rated power, 10S | |
| AC Output Rated Current (A) | 15.7A | 21.7A |
| Output Frequency and Voltage | 50/60Hz; 220Vac/230Vac/240Vac (Single phase) | |
| PV String Input Data | ||
| Max. DC Input Power | 4680W | 6500W |
| PV Input Voltage (V) | 370V(100V~500V) | 370V(100V~500V) |
| MPPT Range (V) | 125V- 425V | 125V- 425V |
| Start-up Voltage(V) | 125V | 125V |
| PV Input Current (A) | 11A+11A | 11A+11A |
| No. of MPPT Trackers | 2 | 2 |
| No. of Strings per MPPT Trackers | 1 / 1 | 1 / 1 |
| General Data | ||
| Weight (Kg) | 20.5 KG | 20.5 KG |
| Size (Length*Width*Height mm) | 580x330x217mm | 580x330x217mm |
Solar Inverter Model HB-H-8K-EU
This solar inverter is suitable for high energy production/consumption, it is used for huge buildings with numerous facilities. The following are the specifications concerning HB-H-8K-EU
| HB-H-8K-EU | |
| Battery Input Data | |
| Max. Charging Current (A) | 190A |
| Max. Discharging Current(A) | 190A |
| Charging Curve | 3 Stages/ Equalization |
| External temperature sensor | Optional |
| Charging strategy for Li-Ion Battery | Self-adaptation to BMS |
| PV String Input Data | |
| Max. DC Input Power | 9880W |
| PV Input Voltage (V) | 370V(100V~500V) |
| MPPT Range (V) | 125V- 425V |
| Start-up Voltage(V) | 125V |
| PV Input Current (A) | 18A+18A |
| No. of MPPT Trackers | 2 |
| No. of Strings per MPPT Trackers | 2+2 |
| AC Output Data | |
| Rated AC Output and UPS Power (W) | 7600W |
| Max AC Output Power (W) | 8360W |
| AC Output Rated Current (A) | 31.7A/33A |
| Max. AC Current (A) | 36.4A/38A |
| Max Continuous AC Passthrough (A) | 50A |
| Output Frequency and Voltage | 50/60Hz; 180Vac – 24Vac |
| Grid Type | Single Phase |
| Current Harmonic Distortion | THD <3% (Linear load <1.5%) |
| Efficiency | |
| Max. Efficiency | 97.60% |
| Euro Efficiency | 97.00% |
| MPPT Efficiency | 99.90% |
| General Data | |
| Weight (Kg) | 20.5 KG |
| Size (Length*Width*Height mm) | 580x330x217mm |
For more information, send us your request:
